The 2026 Honda Ridgeline combines midsize truck capability with a fully integrated body structure, standard All-Wheel Drive, and a V6 powertrain configuration engineered for daily driving, towing, cargo management, and off-road support. Across the Sport, RTL, TrailSport, and Black Edition trims, the 2026 Honda Ridgeline maintains a consistent mechanical platform while introducing trim-specific equipment focused on comfort, utility, and terrain adaptability. The truck incorporates a naturally aspirated V6 engine, a 9-speed automatic transmission, Intelligent Variable Torque Management All-Wheel Drive, and multiple cargo-focused design elements that support both work-related and recreational applications.
V6 Engine Architecture and Power Delivery
Every 2026 Honda Ridgeline is powered by a 3.5-liter V6 engine with a displacement of 3,471 cubic centimeters. The engine produces 280 horsepower at 6,000 rpm and 262 lb-ft of torque at 4,700 rpm. This output is supported by a 24-valve SOHC i-VTEC® valvetrain, direct fuel injection, and an 11.5:1 compression ratio.
The engine operates with a redline of 6,800 rpm and incorporates several efficiency-focused technologies. Variable Cylinder Management™ allows the engine to adjust cylinder operation during lower-load conditions to reduce fuel consumption. Direct fuel injection improves combustion precision and throttle response. Eco Assist™ and Idle-Stop systems contribute additional efficiency support during stop-and-go driving situations.
Honda equips the 2026 Honda Ridgeline with Active Control Engine Mount technology to help reduce vibration transfer into the cabin. A high-capacity radiator with dual high-power cooling fans supports thermal stability during towing and sustained operation. The truck is also equipped with a Direct Ignition System with Immobilizer for ignition control and vehicle security integration.
Nine-Speed Transmission and Intelligent All-Wheel Drive
All trims of the 2026 Honda Ridgeline use a 9-speed automatic transmission paired with Shift-By-Wire controls and paddle shifters. The transmission provides closely spaced lower gear ratios for improved acceleration and higher gears designed for reduced engine load during highway driving. First gear uses a 4.713 ratio, while ninth gear uses a 0.480 ratio. Reverse gear uses a 3.83 ratio, and the final drive ratio is 4.33.
The 2026 Honda Ridgeline also includes Intelligent Variable Torque Management All-Wheel Drive as standard equipment. This system continuously distributes torque based on traction conditions and wheel demand. It is designed to support wet pavement driving, light off-road conditions, gravel surfaces, and low-traction environments.
Intelligent Traction Management allows the driver to select Normal, Snow, Sand, and Mud driving modes. Each mode adjusts throttle response, transmission behavior, and torque distribution to align with changing road conditions. The TrailSport trim further enhances off-road capability by adding an off-road-tuned suspension system and all-terrain tires.
A heavy-duty transmission cooler is standard across all trims. This component supports drivetrain temperature control during towing operations and extended driving under load.
Fuel Economy and Emissions Configuration
The 2026 Honda Ridgeline uses regular unleaded fuel and includes a 19.5-gallon fuel tank. Sport, RTL, and Black Edition trims receive EPA fuel economy ratings of 18 mpg city, 24 mpg highway, and 21 mpg combined. The TrailSport trim receives EPA ratings of 18 mpg city, 23 mpg highway, and 20 mpg combined due to its all-terrain tire configuration and suspension adjustments.
The 2026 Honda Ridgeline is certified as a LEV4-ULEV70 vehicle under California Air Resources Board emissions standards. Honda integrates multiple efficiency and emissions-control technologies throughout the powertrain system to support these ratings.
Disclaimer: *18 city/24 highway/21 combined mpg rating for Sport, RTL & Black Edition trims. 18 city/23 highway/20 combined mpg rating for TrailSport trims. Based on 2026 EPA mileage ratings. Use for comparison purposes only. Your mileage will vary depending on how you drive and maintain your vehicle, driving conditions and other factors.
Chassis Engineering and Suspension Control
The 2026 Honda Ridgeline is built on a fully integrated unit-body chassis with Advanced Compatibility Engineering™ body structure technology. This design distributes crash energy through multiple structural pathways while also supporting overall chassis rigidity.
Front suspension duties are handled by a MacPherson® strut configuration, while the rear uses a multi-link suspension system.
Electric power-assisted rack-and-pinion steering comes standard on all trims. The steering ratio measures 15.86:1, and the steering system requires 3.04 turns lock-to-lock. The curb-to-curb turning diameter measures 43.4 feet.
The braking system uses 12.6-inch ventilated front disc brakes and 13.0-inch solid rear disc brakes. Vehicle Stability Assist™ with Traction Control, Electronic Brake Distribution, Brake Assist, and Anti-Lock Braking System functionality are included across the lineup.
TrailSport models receive an off-road tuned suspension configuration specifically calibrated for uneven terrain and loose surfaces. All trims maintain a ground clearance of 7.64 inches in unladen form.
Truck Bed Engineering and Cargo Management
The 2026 Honda Ridgeline includes a cargo bed engineered for flexible storage and equipment transportation. Truck bed length measures 64.0 inches with the tailgate closed and 83.0 inches with the tailgate open. Bed width measures 50.0 inches between the wheel wells, 51.0 inches at the D-pillars, and 60.0 inches at the bed walls.
Total truck bed cargo volume measures 33.9 cubic feet. The 2026 Honda Ridgeline also incorporates an In-Bed Trunk with 7.3 cubic feet of enclosed storage capacity beneath the bed floor. This compartment provides additional protected storage space for smaller cargo items, tools, or equipment.
The dual-action tailgate can open downward in a traditional manner or swing outward from the side for easier bed access. Heavy-duty tie-down cleats are integrated into the cargo bed, and each cleat supports up to 350 pounds of capacity. Eight tie-down cleats are included as standard equipment.
All trims include truck-bed lighting, while the Black Edition adds LED truck-bed lighting and a 150-watt/400-watt truck-bed power outlet. An integrated Class III trailer hitch with a 7-pin connector is also standard across the lineup.
Towing Capacity and Vehicle Weight Specifications
The 2026 Honda Ridgeline supports a maximum towing capacity of 5,000 pounds when properly equipped. Gross Combined Weight Rating measures 9,986 pounds, while Gross Vehicle Weight Rating measures 6,019 pounds.
Curb weight varies by trim. The Sport trim weighs 4,420 pounds, the RTL weighs 4,480 pounds, the TrailSport weighs 4,495 pounds, and the Black Edition weighs 4,504 pounds.
Payload capacity also differs slightly by trim level. The Sport trim supports 1,583 pounds of payload capacity. The RTL supports 1,544 pounds, the TrailSport supports 1,521 pounds, and the Black Edition supports 1,509 pounds.
